Screen | 2.8 inch Colour TFT LCD |
Input | Keypad |
Applicable Syringes | 5ml,10ml,20ml,30ml,50/60ml |
Accuracy | 2% |
Flow rate | 0.1-1500 ml/h |
Infusion Modes | 3 modes (Rate mode, Time mode, Body Weight mode) |
Mico Mode | Support |
Standby Mode | Support ,standyby time 0-23h59m adjustable |
VTBI(volume to be infused) | 0-9999 ml |
Purge | Support |
Parameters enlarge | Support |
Titration | Support |
Bolus | Manual/ Programmable Bolus |
DPS( Dynamic Pressure Show) | Support |
Keypad lock | Support |
KVO Rate | 0.1-5.0 ml/h |
Brightness | Adjustable |
Anti-bolus | Automatically |
Occlusion Level | 3 Levels |
"Alarm Information (audible and visible)" | VTBI near end,VTBI infused,Pressure high,Battery nearly empty,Battery empty,No power supply,Reminder,KVO finished |
DrugLib | YES, built-in 60 drugs |
History Record | More than 2000 Logs |
Battery life | 12 hours at 5ml/h |
Wireless | WIFI (Optional) |
Interface | MINI USB |
Classification | Nurse call, RS232,Data Export |
Water proof | Support |
Power Supply | "AC:110V-240V, 50/60Hz DC:12V" |
Certificates | CE/ISO13485/CFDA |
Calibration | Automatically |
Upgrade Tool | Andriod Systems Mobile Cable |
Weight | Approx 1.7 kg |
Dimmensions | 400(L)*99(W)*120(H) mm |
Environment Condition | T:5~40°C, H: 10%~95%
P:86.0kPa~106.0kPa |
